372

14 CFR Ch. I (1–1–19 Edition)

Pt. 125, App. E

The recorded values must meet the designated range, resolution and accuracy requirements during static and dynamic condi-

tions. Dynamic condition means the parameter is experiencing change at the maximum rate attainable, including the maximum
rate of reversal. All data recorded must be correlated in time to within one second.

Parameters Range

Accuracy (sensor

input)

Seconds per

sampling interval

Resolution Remarks

11. Longitudinal

Acceleration.

±

1g ....................

±

1.5% max.

range exclud-
ing datum
error of

±

5%.

0.25 ...................

0.004g.

12a. Pitch con-

trol(s) position
(nonfly-by-wire
systems)

18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.5% of full

range.

For airplanes that have a

flight control breakaway
capability that allows either
pilot to operate the controls
independently, record both
control inputs. The control
inputs may be sampled al-
ternately once per second
to produce the sampling in-
terval of 0.5 or 0.25, as ap-
plicable.

12b. Pitch con-

trol(s) position
(fly-by-wire sys-
tems)

3 18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.2% of full

range.

13a. Lateral con-

trol position(s)
(nonfly-by-
wire)

18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.2% of full

range.

For airplanes that have a

flight control break away
capability that allows either
pilot to operate the controls
independently, record both
control inputs. The control
inputs may be sampled al-
ternately once per second
to produce the sampling in-
terval of 0.5 or 0.25, as ap-
plicable.

13b. Lateral con-

trol position(s)
(fly-by-wire)

4 18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.2% of full

range.

14a.Yaw control

position(s)
(nonfly-by-
wire)

5 18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 .....................

0.3% of full

range.

For airplanes that have a

flight control breakaway
capability that allows either
pilot to operate the controls
independently, record both
control inputs. The control
inputs may be sampled al-
ternately once per second
to produce the sampling in-
terval of 0.5.

14b. Yaw control

position(s) (fly-
by-wire)

18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 .....................

0.2% of full

range.

15. Pitch control

surface(s) posi-
tion

6 18

.

Full range ..........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.3% of full

range.

For airplanes fitted with mul-

tiple or split surfaces, a
suitable combination of in-
puts is acceptable in lieu of
recording each surface
separately. The control
surfaces may be sampled
alternately to produce the
sampling interval of 0.5 or
0.25, as applicable.

16. Lateral control

surface(s) posi-
tion

7 18

.

Full Range .........

±

2

°

unless high-

er accuracy
uniquely re-
quired.

0.5 or 0.25 for

airplanes oper-
ated under
§ 125.226(f).

0.2% of full

range.

A suitable combination of

surface position sensors is
acceptable in lieu of re-
cording each surface sepa-
rately. The control surfaces
may be sampled alter-
nately to produce the sam-
pling interval of 0.5 or
0.25, as applicable.
