crewmembers to determine whether external
doors and exits, for which the initial opening
movement is outward, are fully locked. In
addition, there must be a visual means to
signal to crewmembers when normally used
external doors are closed and fully locked.

(c) The passenger entrance door must qual-

ify as a floor level emergency exit. Each ad-
ditional required emergency exit except floor
level exits must be located over the wing or
must be provided with acceptable means to
assist the occupants in descending to the
ground. In addition to the passenger en-
trance door:

(1) For a total seating capacity of 15 or

less, an emergency exit as defined in FAR
23.807(b) is required on each side of the cabin.

(2) For a total seating capacity of 16

through 23, three emergency exits as defined
in FAR 23.807(b) are required with one on the
same side as the door and two on the side op-
posite the door.

(d) An evacuation demonstration must be

conducted utilizing the maximum number of
occupants for which certification is desired.
It must be conducted under simulated night
conditions utilizing only the emergency
exits on the most critical side of the aircraft.
The participants must be representative of
average airline passengers with no previous
practice or rehearsal for the demonstration.
Evacuation must be completed within 90 sec-
onds.

(e) Each emergency exit must be marked

with the word ‘‘Exit’’ by a sign which has
white letters 1 inch high on a red back-
ground 2 inches high, be self-illuminated or
independently internally electrically illumi-
nated, and have a minimum luminescence
(brightness) of at least 160 microlamberts.
The colors may be reversed if the passenger
compartment illumination is essentially the
same.

(f) Access to window type emergency exits

must not be obstructed by seats or seat
backs.

(g) The width of the main passenger aisle

at any point between seats must equal or ex-
ceed the values in the following table:

Total seating capacity

Minimum main passenger

aisle width

Less than 25

inches from

floor

25 inches
and more
from floor

10 through 23 .........................

9 inches .......

15 inches.

Miscellaneous

33.

Lightning strike protection.

Parts that

are electrically insulated from the basic air-
frame must be connected to it through light-
ning arrestors unless a lightning strike on
the insulated part—

(a) Is improbable because of shielding by

other parts; or

(b) Is not hazardous.

34.

Ice protection.

If certification with ice

protection provisions is desired, compliance
with the following must be shown:

(a) The recommended procedures for the

use of the ice protection equipment must be
set forth in the Airplane Flight Manual.

(b) An analysis must be performed to es-

tablish, on the basis of the airplane’s oper-
ational needs, the adequacy of the ice protec-
tion system for the various components of
the airplane. In addition, tests of the ice pro-
tection system must be conducted to dem-
onstrate that the airplane is capable of oper-
ating safely in continuous maximum and
intermittent maximum icing conditions as
described in appendix C of part 25 of this
chapter.

(c) Compliance with all or portions of this

section may be accomplished by reference,
where applicable because of similarity of the
designs, to analysis and tests performed by
the applicant for a type certificated model.

35.

Maintenance information.

The applicant

must make available to the owner at the
time of delivery of the airplane the informa-
tion the applicant considers essential for the
proper maintenance of the airplane. That in-
formation must include the following:

(a) Description of systems, including elec-

trical, hydraulic, and fuel controls.

(b) Lubrication instructions setting forth

the frequency and the lubricants and fluids
which are to be used in the various systems.

(c) Pressures and electrical loads applica-

ble to the various systems.

(d) Tolerances and adjustments necessary

for proper functioning.

(e) Methods of leveling, raising, and tow-

ing.

(f) Methods of balancing control surfaces.
(g) Identification of primary and secondary

structures.

(h) Frequency and extent of inspections

necessary to the proper operation of the air-
plane.

(i) Special repair methods applicable to the

airplane.

(j) Special inspection techniques, such as

X-ray, ultrasonic, and magnetic particle in-
spection.

(k) List of special tools.

Propulsion

General

36.

Vibration characteristics.

For turbo-

propeller powered airplanes, the engine in-
stallation must not result in vibration char-
acteristics of the engine exceeding those es-
tablished during the type certification of the
engine.

37.

In flight restarting of engine.

If the en-

gine on turbopropeller powered airplanes
cannot be restarted at the maximum cruise
altitude, a determination must be made of
the altitude below which restarts can be con-
sistently accomplished. Restart information
