856
14 CFR Ch. I (1–1–19 Edition)
§ 171.311
fall times shall be less then 10 micro-
seconds. It shall be permissible to se-
quentially transmit two pulses in each
out-of-coverage indication time slot.
Where pulse pairs are used, the dura-
tion of each pulse shall be at least 50
microseconds, and the rise and fall
times shall be less then 10 microsec-
onds. The transmission of out-of-cov-
erage indication pulses radiated from
antennas with overlapping coverage
patterns shall be separated by at least
10 microseconds.
N
OTE
: If desired, two pulses may be sequen-
tially transmitted in each OCI time slot.
Where pulse pairs are used, the duration of
each pulse must be 45 (
±
5) microseconds and
the rise and fall times must be less than 10
microseconds.
(D)
System test.
Time slots are pro-
vided in Tables 4a and 4b to allow radi-
ation of TO and FRO test pulses. How-
ever, radiation of these pulses is not re-
quired since the characteristics of
these pulses have not yet been stand-
ardized.
(iii)
Angle encoding.
The encoding
must be as follows:
(A)
General.
Azimuth and elevation
angles are encoded by scanning a nar-
row beam between the limits of the
proportional coverage sector first in
one direction (the TO scan) and then in
the opposite direction (the FRO scan).
Angular information must be encoded
by the amount of time separation be-
tween the beam centers of the TO and
FRO scanning beam pulses. The TO and
FRO transmissions must be symmetri-
cally disposed about the midscan point
listed in Tables 4a, 4b, 5, and 7. The
midscan point and the center of the
time interval between the TO and FRO
scan transmissions must coincide with
a tolerance of
±
10 microseconds. Angu-
lar coding must be linear with angle
and properly decoded using the for-
mula:
θ
=
V
2
T
t
0
−
(
)
where:
q
= Receiver angle in degrees.
V = Scan velocity in degrees per micro-
second.
T
0
= Time separation in microseconds be-
tween TO and FRO beam centers cor-
responding to zero degrees.
t = Time separation in microseconds between
TO and FRO beam centers.
The timing requirements are listed in
Table 6 and illustrated in Figure 7.
