452
49 CFR Ch. I (10–1–18 Edition)
Pt. 172, App. A
and tolerances described in table 2 approxi-
mate those described in table 1 while allow-
ing for differences in production methods
and materials used to manufacture labels
and placards surfaced with printing inks.
Primarily, the color charts based on table 1
are for label or placard colors applied as
opaque coatings such as paint, enamel or
plastic, whereas color charts based on table
2 are intended for use with labels and plac-
ards surfaced only with inks.
For labels printed directly on packaging
surfaces, table 3 may be used, although com-
pliance with either table 1 or table 2 is suffi-
cient. However, if visual reference indicates
that the colors of labels printed directly on
package surfaces are outside the table 1 or 2
tolerances, a spectrophotometer or other in-
strumentation may be required to insure
compliance with table 3.
T
ABLE
1—S
PECIFICATIONS FOR
C
OLOR
T
OLERANCE
C
HARTS FOR
U
SE
W
ITH
L
ABELS AND
P
LACARDS
S
URFACED
W
ITH
P
AINT
, L
ACQUER
, E
NAMEL
, P
LASTIC
, O
THER
O
PAQUE
C
OATINGS
,
OR
I
NK
1
Color Munsell
notations
CIE data for source C
Y x y
Red:
Central color ................................................................
7.5R 4.0/14 ....................................
12.00 .5959 .3269
Orange .........................................................................
8.5R 4.0/14 ....................................
12.00 .6037 .3389
Purple and vivid ...........................................................
6.5R 4.0/14 ....................................
12.00 .5869 .3184
Grayish ........................................................................
7.5R 4.0/12 ....................................
12.00 .5603 .3321
Vivid .............................................................................
7.5R 4.0/16 ....................................
12.00 .6260 .3192
Light .............................................................................
7.5R 4.5/14 ....................................
15.57 .5775 .3320
Dark .............................................................................
7. 5R 3.5/14 ...................................
09.00 .6226 .3141
Orange:
Central color ................................................................
5.OYR 6.0/15 .................................
30.05 .5510 .4214
Yellow and Grayish .....................................................
6.25YR 6.0/15 ................................
30.05
.5452 .4329
Red and vivid ..............................................................
3.75YR 6.0/15 ................................
30.05
.5552 .4091
Grayish ........................................................................
5.OYR 6.0/13 .................................
30.05 .5311 .4154
Vivid .............................................................................
5.OYR 6.0/16 .................................
30.05 .5597 .4239
Light .............................................................................
5.OYR 6.5/15 .................................
36.20 .5427 .4206
Dark .............................................................................
5.OYR 5.5/15 .................................
24.58 .5606 .4218
Yellow:
Central color ................................................................
5.OY 8.0/12 ....................................
59.10 .4562 .4788
Green ...........................................................................
6.5Y 8.0/12 .....................................
59.10 .4498 .4865
Orange and vivid .........................................................
3.5Y 8.0/12 .....................................
59.10
.4632 .4669
Grayish ........................................................................
5.OY 8.0/10 ....................................
59.10 .4376 .4601
Vivid .............................................................................
5.OY 8.0/14 ....................................
59.10 .4699 .4920
Light .............................................................................
5.OY 8.5/12 ....................................
68.40 .4508 .4754
Dark .............................................................................
5.OY 7.5/12 ....................................
50.68 .4620 .4823
Green:
Central color ................................................................
7.5G 4.0/9 ......................................
12.00 .2111 .4121
Bluish ...........................................................................
0.5BG 4.0/9 ....................................
12.00 .1974 .3809
Green-yellow ...............................................................
5.0G 4.0/9 ......................................
12.00 .2237 .4399
Grayish A .....................................................................
7.5G 4.0/7 ......................................
12.00 .2350 .3922
Grayish B
2
...................................................................
7.5G 4.0/6 ......................................
12.00
.2467
.3822
Vivid .............................................................................
7.5G 4.0/11 ....................................
12.00 .1848 .4319
Light .............................................................................
7.5G 4.5/9 ......................................
15.57 .2204 .4060
Dark .............................................................................
7.5G 3.5/9 ......................................
09.00 .2027 .4163
Blue:
Central color ................................................................
2.5PB 3.5/10 ..................................
09.00 .1691 .1744
Purple ..........................................................................
4.5PB 3.5/10 ..................................
09.00 .1796 .1711
Green and vivid ...........................................................
10.0B 3.5/10 ...................................
09.00
.1557 .1815
Grayish ........................................................................
2.5PB 3.5/8 ....................................
09.00 .1888 .1964
Vivid .............................................................................
2.5PB 3.5/12 ..................................
09.00 .1516 .1547
Light .............................................................................
2.5PB 4.0/10 ..................................
12.00 .1805 .1888
Dark .............................................................................
2.5PB 3.0/10 ..................................
06.55 .1576 .1600
Purple:
Central color ................................................................
10.0P 4.5/10 ...................................
15.57 .3307 .2245
Reddish purple ............................................................
2.5RP 4.5/10 ..................................
15.57
.3584 .2377
Blue purple ..................................................................
7.5P 4.5/10 .....................................
15.57 .3068 .2145
Reddish gray ...............................................................
10.0P 4.5/8 .....................................
15.57 .3280 .2391
Gray
2
...........................................................................
10.0P 4.5/6.5 ..................................
15.57 .3254 .2519
Vivid .............................................................................
10.0P 4.5/12 ...................................
15.57 .3333 .2101
Light .............................................................................
10.0P 5.0/10 ...................................
19.77 .3308 .2328
Dark .............................................................................
10.0P 4.0/10 ...................................
12.00 .3306 .2162
1
Maximum chroma is not limited.
2
For the colors green and purple, the minimum saturation (chroma) limits for porcelain enamel on metal are lower than for
most other surface coatings. Therefore, the minimum chroma limits of these two colors as displayed on the Charts for compari-
son to porcelain enamel on metal is low, as shown for green (grayish B) and purple (gray).
N
OTE
: CIE = Commission Internationale de L’Eclairage.
