584

14 CFR Ch. I (1–1–14 Edition)

Pt. 25, App. F

(6) Leave the burner in position for 15 sec-

onds and then remove to a position at least
2 inches (51 mm) above the specimen.

(g) Report. (1) Identify and describe the

test specimen.

(2) Report any shrinkage or melting of the

test specimen.

(3) Report the flame propagation distance.

If this distance is less than 2 inches, report
this as a pass (no measurement required).

(4) Report the after-flame time.
(h)

Requirements.  (1) There must be no

flame propagation beyond 2 inches (51 mm)

to the left of the centerline of the pilot
flame application.

(2) The flame time after removal of the

pilot burner may not exceed 3 seconds on any
specimen.

Part VII—Test Method To Determine the

Burnthrough Resistance of Thermal/Acoustic
Insulation Materials

Use the following test method to evaluate

the burnthrough resistance characteristics
of aircraft thermal/acoustic insulation mate-
rials when exposed to a high intensity open
flame.
