(3) The impact to the front of the en-

gine from the large single bird, the sin-
gle largest medium bird which can
enter the inlet, and the large flocking
bird must be evaluated. Applicants
must show that the associated compo-
nents when struck under the condi-
tions prescribed in paragraphs (b), (c)
or (d) of this section, as applicable, will
not affect the engine to the extent that
the engine cannot comply with the re-
quirements of paragraphs (b)(3), (c)(6)
and (d)(4) of this section.

(4) For an engine that incorporates

an inlet protection device, compliance
with this section shall be established
with the device functioning. The en-
gine approval will be endorsed to show
that compliance with the requirements
has been established with the device
functioning.

(5) Objects that are accepted by the

Administrator may be substituted for
birds when conducting the bird inges-
tion tests required by paragraphs (b),
(c) and (d) of this section.

(6) If compliance with the require-

ments of this section is not estab-
lished, the engine type certification
documentation will show that the en-
gine shall be limited to aircraft instal-
lations in which it is shown that a bird
cannot strike the engine, or be in-
gested into the engine, or adversely re-
strict airflow into the engine.

(b)

Large single bird.Compliance with

the large bird ingestion requirements
shall be in accordance with the fol-
lowing:

(1) The large bird ingestion test shall

be conducted using one bird of a weight
determined from Table 1 aimed at the
most critical exposed location on the
first stage rotor blades and ingested at
a bird speed of 200-knots for engines to
be installed on airplanes, or the max-
imum airspeed for normal rotorcraft
flight operations for engines to be in-
stalled on rotorcraft.

(2) Power lever movement is not per-

mitted within 15 seconds following in-
gestion of the large bird.

(3) Ingestion of a single large bird

tested under the conditions prescribed
in this section may not result in any
condition described in § 33.75(g)(2) of
this part.

(4) Compliance with the large bird in-

gestion requirements of this paragraph

may be shown by demonstrating that
the requirements of § 33.94(a) constitute
a more severe demonstration of blade
containment and rotor unbalance than
the requirements of this paragraph.

T

ABLE

1

TO

§ 33.76—L

ARGE

B

IRD

W

EIGHT



R

EQUIREMENTS



Engine Inlet Throat Area

(A)—Square-meters (square-

inches)

Bird weight kg. (lb.)

1.35 (2,092)>A .......................

1.85 (4.07) minimum, unless

a smaller bird is deter-
mined to be a more severe
demonstration.

1.35 (2,092)

≤

A<3.90 (6,045)

2.75 (6.05)

3.90 (6,045)

≤

A .......................

3.65 (8.03)

(c)

Small and medium flocking bird.

Compliance with the small and me-
dium bird ingestion requirements shall
be in accordance with the following:

(1) Analysis or component test, or

both, acceptable to the Administrator,
shall be conducted to determine the
critical ingestion parameters affecting
power loss and damage. Critical inges-
tion parameters shall include, but are
not limited to, the effects of bird speed,
critical target location, and first stage
rotor speed. The critical bird ingestion
speed should reflect the most critical
condition within the range of airspeeds
used for normal flight operations up to
1,500 feet above ground level, but not
less than V

1

minimum for airplanes.

(2) Medium bird engine tests shall be

conducted so as to simulate a flock en-
counter, and will use the bird weights
and quantities specified in Table 2.
When only one bird is specified, that
bird will be aimed at the engine core
primary flow path; the other critical
locations on the engine face area must
be addressed, as necessary, by appro-
priate tests or analysis, or both. When
two or more birds are specified in Table
2, the largest of those birds must be
aimed at the engine core primary flow
path, and a second bird must be aimed
at the most critical exposed location
on the first stage rotor blades. Any re-
maining birds must be evenly distrib-
uted over the engine face area.

(3) In addition, except for rotorcraft

engines, it must also be substantiated
by appropriate tests or analysis or
both, that when the full fan assembly
is subjected to the ingestion of the
quantity and weights of bird from
