940

14 CFR Ch. I (1–1–14 Edition)

Pt. 36, App. A

The airplane reference point for approach
measurements is the instrument landing sys-
tem (ILS) antenna. If no ILS antenna is in-
stalled an alternative reference point must
be approved by the FAA.

A36.9.3

Simplified method of adjustment.

A36.9.3.1

General.  As described below, the

simplified adjustment method consists of ap-
plying adjustments (to the EPNL, which is
calculated from the measured data) for the

differences between measured and reference
conditions at the moment of PNLTM.

A36.9.3.2

Adjustments to PNL and PNLT.

(a) The portions of the test flight path and

the reference flight path described below,
and illustrated in Figure A36–6, include the
noise time history that is relevant to the
calculation of flyover and approach EPNL.
In figure A36–6:
