970

14 CFR Ch. I (1–1–14 Edition)

Pt. 36, App. H

(3) Figure H3 illustrates portions of the

measured and reference approach flight
paths including the significant geometrical
relationships influencing sound propagation.

The measured approach path is represented
by segment EK with an approach allowable
angle

q. Reference positions, E

r

and K

r

, define

an idealized reference approach angle of 6

°
