90

14 CFR Ch. I (1–1–14 Edition)

Pt. 60, App. A

lllllllllllllllllllllll

B

EGIN

I

NFORMATION



16. C

ONTINUING

Q

UALIFICATION

E

VALUATIONS

—

V

ALIDATION

T

EST

D

ATA

P

RESENTATION



a. Background

(1) The MQTG is created during the initial

evaluation of a flight simulator. This is the
master document, as amended, to which
flight simulator continuing qualification
evaluation test results are compared.

(2) The currently accepted method of pre-

senting continuing qualification evaluation
test results is to provide flight simulator re-
sults over-plotted with reference data. Test
results are carefully reviewed to determine if
the test is within the specified tolerances.
This can be a time consuming process, par-
ticularly when reference data exhibits rapid
variations or an apparent anomaly requiring
engineering judgment in the application of
the tolerances. In these cases, the solution is
to compare the results to the MQTG. The
continuing qualification results are com-

pared to the results in the MQTG for accept-
ance. The flight simulator operator and the
NSPM should look for any change in the
flight simulator performance since initial
qualification.

b. Continuing Qualification Evaluation Test

Results Presentation

(1) Flight simulator operators are encour-

aged to over-plot continuing qualification
validation test results with MQTG flight
simulator results recorded during the initial
evaluation and as amended. Any change in a
validation test will be readily apparent. In
addition to plotting continuing qualification
validation test and MQTG results, operators
may elect to plot reference data as well.

(2) There are no suggested tolerances be-

tween flight simulator continuing qualifica-
tion and MQTG validation test results. In-
vestigation of any discrepancy between the
MQTG and continuing qualification flight
simulator performance is left to the discre-
tion of the flight simulator operator and the
NSPM.
