112
14 CFR Ch. I (1–1–14 Edition)
Pt. 60, App. A
T
ABLE
A3C—F
UNCTIONS AND
S
UBJECTIVE
T
ESTS
—Continued
QPS requirements
Entry No.
Additional airport models beyond minimum required for qualification—Class II airport mod-
els
Simulator level
A B C D
End QPS Requirements
Begin Information
8. ....................
Sponsors are not required to provide every detail of a runway, but the detail that is pro-
vided must be correct within the capabilities of the system.
X X X X
End Information
T
ABLE
A3D—F
UNCTIONS AND
S
UBJECTIVE
T
ESTS
QPS Requirements
Information
Entry no.
Motion system effects
Simulator level
Notes
A B C D
This table specifies motion effects that are required to indicate when a flight crewmember must be able to recognize an event
or situation. Where applicable, flight simulator pitch, side loading and directional control characteristics must be representative
of the airplane.
1. ..............
Runway rumble, oleo deflection, ground
speed, uneven runway, runway and taxiway
centerline light characteristics:
Procedure: After the airplane has been pre-
set to the takeoff position and then re-
leased, taxi at various speeds with a
smooth runway and note the general char-
acteristics of the simulated runway rumble
effects of oleo deflections. Repeat the ma-
neuver with a runway roughness of 50%,
then with maximum roughness. Note the
associated motion vibrations affected by
ground speed and runway roughness.
X
X
X
X Different gross weights can also be selected,
which may also affect the associated vibra-
tions depending on airplane type. The asso-
ciated motion effects for the above tests
should also include an assessment of the
effects of rolling over centerline lights, sur-
face discontinuities of uneven runways, and
various taxiway characteristics.
2. ..............
Buffets on the ground due to spoiler/
speedbrake extension and reverse thrust:
Procedure: Perform a normal landing and use
ground spoilers and reverse thrust—either
individually or in combination—to decelerate
the simulated airplane. Do not use wheel
braking so that only the buffet due to the
ground spoilers and thrust reversers is felt.
X X X X
3. ..............
Bumps associated with the landing gear:
Procedure: Perform a normal take-off paying
special attention to the bumps that could be
perceptible due to maximum oleo extension
after lift-off. When the landing gear is ex-
tended or retracted, motion bumps can be
felt when the gear locks into position.
X X X X
4. ..............
Buffet during extension and retraction of land-
ing gear:
Procedure: Operate the landing gear. Check
that the motion cues of the buffet experi-
enced represent the actual airplane.
X X X X
