209

Federal Aviation Administration, DOT

Pt. 60, App. C

T

ABLE

C1A—M

INIMUM

S

IMULATOR

R

EQUIREMENTS

—Continued

Entry No.

QPS requirements

Simulator levels

Information

General simulator requirements

B

C

D

Notes

3.d. ...........

The simulator must provide pilot controls with

control forces and control travel that cor-
respond to the simulated helicopter. The
simulator must also react in the same man-
ner as the helicopter under the same flight
conditions.

X X X

3.e. ...........

Simulator control feel dynamics must replicate

the helicopter simulated. This must be deter-
mined by comparing a recording of the con-
trol feel dynamics of the simulator to heli-
copter measurements. For initial and up-
grade evaluations, the control dynamic char-
acteristics must be measured and recorded
directly from the flight deck controls, and
must be accomplished in takeoff, cruise, and
landing conditions and configurations.

X X

4. ..............

Instructor/Evaluator Facilities

4.a. ...........

In addition to the flight crewmember stations,

the simulator must have at least two suitable
seats for the instructor/check airman and
FAA inspector. These seats must provide
adequate vision to the pilot’s panel and for-
ward windows. All seats other than flight
crew seats need not represent those found
in the helicopter but must be adequately se-
cured to the floor and equipped with similar
positive restraint devices.

X

X

X

The NSPM will consider alternatives to this

standard for additional seats based on
unique flight deck configurations.

4.b. ...........

The simulator must have controls that enable

the instructor/evaluator to control all required
system variables and insert all abnormal or
emergency conditions into the simulated hel-
icopter systems as described in the spon-
sor’s FAA-approved training program, or as
described in the relevant operating manual
as appropriate.

X X X

4.c. ...........

The simulator must have instructor controls for

all environmental effects expected to be
available at the IOS; e.g., clouds, visibility,
icing, precipitation, temperature, storm cells,
and wind speed and direction.

X X X

4.d. ...........

The simulator must provide the instructor or

evaluator the ability to present ground and
air hazards.

X

X

For example, another aircraft crossing the ac-

tive runway and converging airborne traffic.

4.e. ...........

The simulator must provide the instructor or

evaluator the ability to present the effect of
re-circulating dust, water vapor, or snow
conditions that develop as a result of rotor
downwash.

X

X

This is a selectable condition that is not re-

quired for all operations on or near the sur-
face.

5. ..............

Motion System

5.a. ...........

The simulator must have motion (force) cues

perceptible to the pilot that are representa-
tive of the motion in a helicopter.

X

X

X

For example, touchdown cues should be a

function of the rate of descent (RoD) of the
simulated helicopter.

5.b. ...........

The simulator must have a motion (force cue-

ing) system with a minimum of three de-
grees of freedom (at least pitch, roll, and
heave).

An SOC is required.

X
