221
Federal Aviation Administration, DOT
Pt. 60, App. C
1.b.2.
..........
Rate of Turn vs. Pedal De-
flection, Brake Application,
or Nosewheel Angle, as
applicable.
±
10% or
±
2
°
/sec. Turn Rate.
Ground Takeoff
.....................
If brakes are used, brake
pedal position and brake
system pressure must be
matched to the helicopter
flight test value.
X X X
1.b.3.
..........
Taxi
........................................
Pitch Angle—
±
1.5
°
, Torque—
±
3%, Longitudinal Control
Position—
±
5%, Lateral
Control Position—
±
5%, Di-
rectional Control Position—
±
5%, Collective Control Po-
sition—
±
5%.
Ground
...................................
Record results for control po-
sition and pitch attitude
during ground taxi for a
specific ground speed,
wind speed and direction,
and density altitude.
X X X
1.b.4.
..........
Brake Effectiveness
...............
±
10% of time and distance.
Ground
...................................
X
X
X
1.c.
..............
Takeoff
When the speed range for the following tests is less than 40 knots, the applicable airspeed tolerance may be applied to either
airspeed or ground speed, as appropriate.
1.c.1.
...........
All Engines
............................
Airspeed—
±
3 kt, Altitude—
±
20 ft (6.1m), Torque—
±
3%, Rotor Speed—
±
1.5%,
Vertical Velocity—
±
100 fpm
(0.50m/sec) or 10%, Pitch
Attitude—
±
1.5
°
, Bank Atti-
tude—
±
2
°
, Heading—
±
2
°
,
Longitudinal Control Posi-
tion—
±
10%, Lateral Control
Position—
±
10%, Direc-
tional Control Position—
±
10%, Collective Control
Position—
±
10%.
Ground/Takeoff and Initial
Segment of Climb.
Record results of takeoff
flight path as appropriate to
helicopter model simulated
(running takeoff for Level
B, takeoff from a hover for
Level C and D). For Level
B, the criteria apply only to
those segments at air-
speeds above effective
translational lift. Results
must be recorded from the
initiation of the takeoff to at
least 200 ft (61m) AGL.
X X X
1.c.2.
...........
One Engine Inoperative con-
tinued takeoff.
Airspeed—
±
3 kt, Altitude—
±
20 ft (6.1m), Torque—
±
3%, Rotor Speed—
±
1.5%,
Vertical Velocity—
±
100 fpm
(0.50m/sec) or 10%, Pitch
Attitude—
±
1.5
°
, Bank Atti-
tude—
±
2
°
, Heading—
±
2
°
,
Longitudinal Control Posi-
tion—
±
10% Lateral Control
Position—
±
10%, Direc-
tional Control Position—
±
10%, Collective Control
Position—
±
10%.
Ground/Takeoff; and Initial
Segment of Climb.
Record takeoff flight path as
appropriate to helicopter
model simulated. Results
must be recorded from the
initiation of the takeoff to at
least 200 ft (61m) AGL.
X
X
X
Because several kinds of
takeoff procedures can be
performed, the specific
type of takeoff profile
should be recorded to en-
sure the proper takeoff pro-
file comparison test is
used.
