224

14 CFR Ch. I (1–1–14 Edition)

Pt. 60, App. C

T

ABLE

C2A—F

ULL

F

LIGHT

S

IMULATOR

(FFS) O

BJECTIVE

T

ESTS

—Continued

QPS requirements

Information

Test

Tolerance(s)

Flight condition

Test details

Simulator

level

Notes

Entry No.

Title

B C

D

Entry

......................................

Rotor Speed—

±

3%, Pitch At-

titude—

±

2

°

, Roll Attitude—

±

3

°

, Yaw Attitude—

±

5

°

,

Airspeed—

±

5 kts., Vertical

Velocity—

±

200 fpm (1.00

m/sec) or 10%.

Cruise or Climb

.....................

Record results of a rapid

throttle reduction to idle. If

the cruise condition is se-

lected, comparison must be

made for the maximum

range airspeed. If the climb

condition is selected, com-

parison must be made for

the maximum rate of climb

airspeed at or near max-

imum continuous power.

X X

1.j.

...............

Landing

When the speed range for tests 1.j.1., 1.j.2., or 1.j.3. is less than 40 knots, the applicable airspeed tolerance may be applie

d to either airspeed or ground speed, as appro-

priate.

1.j.1.

............

All Engines

............................

Airspeed—

±

3 kts., Altitude—

±

20 ft. (6.1m), Torque—

±

3%, Rotor Speed—

±

1.5%,

Pitch Attitude—

±

1.5

°

, Bank

Attitude—

±

1.5

°

, Heading—

±

2

°

, Longitudinal Control

Position—

±

10%, Lateral

Control Position—

±

10%,

Directional Control Posi-

tion—

±

10%, Collective

Control Position—

±

10%.

Approach

...............................

Record results of the ap-

proach and landing profile

as appropriate to the heli-

copter model simulated

(running landing for Level

B, or approach to a hover

for Level C and D). For

Level B, the criteria apply

only to those segments at

airspeeds above effective

translational lift.

X X X

1.j.2.

............

One Engine Inoperative.

Airspeed—

±

3 kts., Altitude—

±

20 ft. (6.1m), Torque—

±

3%, Rotor Speed—

±

1.5%,

Pitch Attitude—

±

1.5

°

, Bank

Attitude—

±

1.5

°

, Heading—

±

2

°

, Longitudinal Control

Position—

±

10%, Lateral

Control Position—

±

10%,

Directional Control Posi-

tion—

±

10%, Collective

Control Position—

±

10%.

Approach

...............................

Record results for both Cat-

egory A and Category B

approaches and landing as

appropriate to helicopter

model simulated. For Level

B, the criteria apply only to

those segments at air-

speeds above effective

translational lift.

X X X
