14 CFR Ch. I (1–1–14 Edition)

Pt. 60, App. C

T

ABLE

C2A—F

ULL

F

LIGHT

S

IMULATOR

(FFS) O

BJECTIVE

T

ESTS

—Continued

QPS requirements

Information

Test

Tolerance(s)

Flight condition

Test details

Simulator

level

Notes

Entry No.

Title

B C

D

4.b.1.

..........

Continuous field-of-view.

The simulator must provide a

continuous field-of-view of

at least 75

°

horizontally

and 30

°

vertically per pilot

seat or the number of de-

grees necessary to meet

the visual ground segment

requirement, whichever is

greater. Both pilot seat vis-

ual systems must be oper-

able simultaneously. Wide-

angle systems providing

cross-flight deck viewing

(for both pilots simulta-

neously) must provide a

minimum field-of-view of at

least 146

°

horizontally and

36

°

vertically. Any geo-

metric error between the

Image Generator eye point

and the pilot eye point

must be 8

°

or less.

N/A

.........................................

An SOC is required and must

explain the geometry of the

installation.

Additional horizontal field-of-

view capability may be

added at the sponsor’s dis-

cretion provided the min-

imum field-of-view is re-

tained.

X

Horizontal field-of-view is

centered on the zero de-

gree azimuth line relative

to the aircraft fuselage.

Field-of-view may be

measured using a visual

test pattern filling the entire

visual scene (all channels)

with a matrix of black and

white 5

°

squares.
