T

ABLE

C2A—F

ULL

F

LIGHT

S

IMULATOR

(FFS) O

BJECTIVE

T

ESTS

—Continued

QPS requirements

Information

Test

Tolerance(s)

Flight condition

Test details

Simulator

level

Notes

Entry No.

Title

B C

D

4.c.

..............

Surface contrast ratio.

Not less than 5:1.

N/A

.........................................

The ratio is calculate

d by di-

viding the brightness level

of the center, bright square

(providing at least 2 foot-

lamberts or 7 cd/m

2

) by the

brightness level of any ad-

jacent dark square.

X

Measurements may be made

using a 1

°

spot photometer

and a raster drawn test

pattern filling the entire vis-

ual scene (all channels)

with a test pattern of black

and white squares, 5 per

square, with a white square

in the center of each chan-

nel. During contrast ratio

testing, simulator aft-cab

and flight deck ambient

light levels should be zero.

4.d.

.............

Highlight brightness.

Not less than six (6) foot-lam-

berts (20 cd/m

2

).

N/A

.........................................

Measure the brightness of

the center, white square

while superimposing a

highlight on that white

square. The use of calli-

graphic capabilities to en-

hance the raster brightness

is acceptable; however,

measuring light points is

not acceptable.

X

Measurements may be made

using a 1

°

spot photometer

and a raster drawn test

pattern filling the entire vis-

ual scene (all channels)

with a test pattern of black

and white squares, 5 per

square, with a white square

in the center of each chan-

nel.
