T
ABLE
D2A—F
LIGHT
T
RAINING
D
EVICE
(FTD) O
BJECTIVE
T
ESTS
—Continued
QPS requirements
Information
Test
Tolerances
Flight conditions
Test details
FTD level
Notes
Entry No.
Title
5 6 7
1.j.4.
.......................
Autorotational Landing
..
Torque—
±
3%, Rotor Speed—
±
3%, Vertical Velocity—
±
100
fpm (0.50 m/sec) or 10%, Pitch
Attitude—
±
2
°
, Bank Attitude—
±
2
°
, Heading—
±
5
°
, Longitu-
dinal Control Position—
±
10%,
Lateral Control Position—
±
10%, Directional Control Posi-
tion—
±
10%, Collective Control
Position—
±
10%.
Landing
.....................
Record the results of an
autorotational deceleration and
landing from a stabilized
autorotational descent, to touch
down.
X
If flight test data containing
all required parameters
for a complete power-off
landing is not available
from the aircraft manu-
facturer for this test, and
other qualified flight test
personnel are not avail-
able to acquire this data,
the sponsor must coordi-
nate with the NSPM to
determine if it would be
appropriate to accept al-
ternative testing means.
Alternative approaches to
this data acquisition that
may be acceptable are:
(1) A simulated
autorotational flare and
reduction of rate of de-
scent (ROD) at altitude;
or (2) a power-on termi-
nation following an
autorotational approach
and flare.
2. Handling
Qualities
2.a.
........................
Control System Mechan-
ical Characteristics.
Contact the NSPM for clarification
of any issue regarding heli-
copters with reversible controls.
2.a.1.
.....................
Cyclic
.............................
Breakout—
±
0.25 lbs (0.112 daN)
or 25%. Force—
±
1.0 lb (0.224
daN) or 10%.
Ground; Static condi-
tions. Trim On and
Off. Friction Off.
Augmentation On
and Off.
Record results for an uninter-
rupted control sweep to the
stops. (This test does not apply
if aircraft hardware modular
controllers are used.).
X X X
