35

Federal Aviation Administration, DOT

Pt. 60, App. A

T

ABLE

A1A—M

INIMUM

S

IMULATOR

R

EQUIREMENTS

—Continued

QPS requirements

Simulator levels

Information

Entry No.

General simulator requirements

A

B

C

D

Notes

6.o. ...........

Dusk (or Twilight) Visual Scenes. When

used in training, testing, or checking
activities, the simulator must provide
dusk (or twilight) visual scenes with
sufficient scene content to recognize
the airport, the terrain, and major
landmarks around the airport. The
scene content must allow a pilot to
successfully accomplish a visual
landing. Dusk (or twilight) scenes, as
a minimum, must provide full color
presentations of reduced ambient in-
tensity, sufficient surfaces with ap-
propriate textural cues that include
self-illuminated objects such as road
networks, ramp lighting and airport
signage, to conduct a visual ap-
proach, landing and airport move-
ment (taxi). Scenes must include a
definable horizon and typical terrain
characteristics such as fields, roads
and bodies of water and surfaces il-
luminated by airplane landing lights.
If provided, directional horizon light-
ing must have correct orientation and
be consistent with surface shading
effects. Total night or dusk (twilight)
scene content must be comparable
in detail to that produced by 10,000
visible textured surfaces and 15,000
visible lights with sufficient system
capacity to display 16 simultaneously
moving objects.

An SOC is required.

X X

6.p. ...........

Daylight Visual Scenes. The simulator

must provide daylight visual scenes
with sufficient scene content to rec-
ognize the airport, the terrain, and
major landmarks around the airport.
The scene content must allow a pilot
to successfully accomplish a visual
landing. Any ambient lighting must
not ‘‘washout’’ the displayed visual
scene. Total daylight scene content
must be comparable in detail to that
produced by 10,000 visible textured
surfaces and 6,000 visible lights with
sufficient system capacity to display
16 simultaneously moving objects.
The visual display must be free of
apparent and distracting quantization
and other distracting visual effects
while the simulator is in motion.

An SOC is required.

X X

6.q. ...........

The simulator must provide operational

visual scenes that portray physical
relationships known to cause landing
illusions to pilots.

X  X  For example: short runways, landing approaches

over water, uphill or downhill runways, rising ter-
rain on the approach path, unique topographic
features.
