50

14 CFR Ch. I (1–1–14 Edition)

Pt. 60, App. A

T

ABLE

A2A—F

ULL

F

LIGHT

S

IMULATOR

(FFS) O

BJECTIVE

T

ESTS

—Continued

QPS Requirements

Information

Test

Tolerance

Flight conditions

Test details

Simulator level

Notes

Entry No.

Title

A B

2.a.5.

.............

Rudder Pedal Steering

Calibration.

±

2

°

nosewheel

angle

...........

Ground

.........................

Record results of an uninterrupted con-

trol sweep to the stops.

X X X X

2.a.6.

.............

Pitch Trim Indicator vs.

Surface Position Cali-

bration.

±

0.5

°

of computed trim sur-

face angle.

Ground

.........................

The purpose of the

test is to compare

FFS against design

data or equivalent.

2.a.7.

.............

Pitch Trim Rate

...............

±

10% trim rate (

°

/sec)

..........

Ground

and

approach

The trim rate must be checked using the

pilot primary trim (ground) and using

the autopilot or pilot primary trim in

flight at go-around flight conditions.

X X X X

2.a.8.

.............

Alignment of Flight Deck

Throttle Lever vs. Se-

lected Engine Param-

eter.

±

5

°

of throttle lever angle, or

±

3% N1, or

±

.03 EPR, or

±

3% maximum rated

manifold pressure, or

±

3%

torque. For propeller-driv-

en airplanes where the

propeller control levers do

not have angular travel, a

tolerance of

±

0.8 inch (

±

cm.) applies.

Ground

.........................

Requires simultaneous recording for all

engines. The tolerances apply against

airplane data and between engines. In

the case of propeller powered air-

planes, if a propeller lever is present,

it must also be checked. For airplanes

with throttle ‘‘detents,’’ all detents must

be presented. May be a series of

snapshot test results.

X X X X

2.a.9.

.............

Brake Pedal Position vs.

Force and Brake Sys-

tem Pressure Calibra-

tion.

±

5 lb (2.2 daN) or 10%

force,

±

150 psi (1.0 MPa)

or

±

10% brake system

pressure.

Ground

.........................

Hydraulic system pressure must be re-

lated to pedal position through a

ground static test.

X X X X

FFS

computer

output

results may be used

to show compliance.

2.b.

................

Dynamic Control Tests.

..................

Tests 2.b.1., 2.b.2., and 2.b.3. are not applicable if dynamic response is generated solely by use of airplan

e hardware in the

FFS. Power setting is that required for level flight unless otherwise specified.

....

....

....

....
