52

14 CFR Ch. I (1–1–14 Edition)

Pt. 60, App. A

T

ABLE

A2A—F

ULL

F

LIGHT

S

IMULATOR

(FFS) O

BJECTIVE

T

ESTS

—Continued

QPS Requirements

Information

Test

Tolerance

Flight conditions

Test details

Simulator level

Notes

Entry No.

Title

A B

C

D

2.b.2.

.............

Roll Control

.....................

For underdamped systems:

±

10% of time from 90% of

initial displacement (0.9

A

d

) to first zero crossing,

and

±

10 (n+1)% of period

thereafter.

±

10% ampli-

tude of first overshoot, ap-

plied to all overshoots

greater than 5% of initial

displacement (.05 A

d

),

±

1

overshoot (first significant

overshoot must be

matched). For over-

damped systems:

±

10% of

time from 90% of initial

displacement (0.9 A

d

) to

10% of initial displace-

ment (0.1A

d

). For the al-

ternate method see para-

graph 4 of this attach-

ment. The slow sweep is

the equivalent to the static

test 2.a.2. For the mod-

erate and rapid sweeps:

±

2 lb (0.9 daN) or

±

10%

dynamic increment above

the static force.

Takeoff, Cruise, and

Landing.

Data must show normal control displace-

ment in both directions. Tolerance ap-

plies against the absolute values of

each period (considered independ-

ently). Normal control displacement for

this test is 25% to 50% of the max-

imum allowable roll controller deflec-

tion for flight conditions limited by the

maneuvering load envelope.

X

X

‘‘n’’ is the sequential

period of a full cycle

of oscillation. Refer

to paragraph 4 of

this attachment for

more information.

Static and dynamic

flight control tests

should be accom-

plished at the same

feel or impact pres-

sures.
