Federal Aviation Administration, DOT

Pt. 60, App. A

..................

Not greater than two (2) arc

minutes.

N/A

...............................

An SOC is required and must include

the relevant calculations and an expla-

nation of those calculations. This re-

quirement is applicable to any level of

simulator equipped with a daylight vis-

ual system.

X

X

When the eye is posi-

tioned on a 3

°

glide

slope at the slant

range distances indi-

cated with white run-

way markings on a

black runway sur-

face, the eye will

subtend two (2) arc

minutes: (1) A slant

range of 6,876 ft

with stripes 150 ft

long and 16 ft wide,

spaced 4 ft apart.

(2) For Configuration

A; a slant range of

5,157 feet with

stripes 150 ft long

and 12 ft wide,

spaced 3 ft apart.

(3) For Configuration

B; a slant range of

9,884 feet, with

stripes 150 ft long

and 5.75 ft wide,

spaced 5.75 ft apart.

4.g.

................

Light point size.

..................

Not greater than five (5) arc-

minutes.

N/A

...............................

An SOC is required and must include

the relevant calculations and an expla-

nation of those calculations. This re-

quirement is applicable to any level of

simulator equipped with a daylight vis-

ual system.

X

X

Light point size should

be measured using

a test pattern con-

sisting of a centrally

located single row of

light points reduced

in length until modu-

lation is just discern-

ible in each visual

channel. A row of 48

lights will form a 4

°

angle or less.

4.h.

................

Light point contrast ratio.
