graduated cylinder for a 2-minute period. De-
termine the flow rate in gallons per hour.
The fuel flow rate must be 6.0

±

0.2 gallons per

hour (0.378

±

0.0126 L/min).

(e)

Calibration.  (1) Position the burner in

front of the calorimeter so that it is centered
and the vertical plane of the burner cone exit
is 4

±

0.125 inches (102

±

3 mm) from the calo-

rimeter face. Ensure that the horizontal cen-
terline of the burner cone is offset 1 inch
below the horizontal centerline of the calo-
rimeter (figure 8). Without disturbing the
calorimeter position, rotate the burner in
front of the thermocouple rake, such that
the middle thermocouple (number 4 of 7) is
centered on the burner cone.
