100
14 CFR Ch. I (1–1–14 Edition)
Pt. 60, App. A
(2) Early CGI visual systems are excepted
from the requirement of including runway
numbers unless the runways are used for
LOFT training sessions. These LOFT airport
models require runway numbers but only for
the specific runway end (one direction) used
in the LOFT session. The systems required
to display runway numbers only for LOFT
scenes are:
(a) FlightSafety VITAL IV.
(b) Redifusion SP3 and SP3T.
(c) Link-Miles Image II.
(3) The following list of previously quali-
fied CGI and display systems are incapable of
generating blue lights. These systems are
not required to have accurate taxi-way edge
lighting:
(a) Redifusion SP1.
(b) FlightSafety Vital IV.
(c) Link-Miles Image II and Image IIT
(d) XKD displays (even though the XKD
image generator is capable of generating
blue colored lights, the display cannot ac-
commodate that color).
E
ND
I
NFORMATION
lllllllllllllllllllllll
T
ABLE
A3A—F
UNCTIONS AND
S
UBJECTIVE
T
ESTS
QPS Requirements
Entry No.
Operations tasks
Simulator level
A B C D
Tasks in this table are subject to evaluation if appropriate for the airplane simulated as indicated in the SOQ Configuration
List or the level of simulator qualification involved. Items not installed or not functional on the simulator and, therefore, not
appearing on the SOQ Configuration List, are not required to be listed as exceptions on the SOQ.
1. .........................
Preparation For Flight .........................................................................................................
Preflight. Accomplish a functions check of all switches, indicators, systems, and equip-
ment at all crewmembers’ and instructors’ stations and determine that the flight deck
design and functions are identical to that of the airplane simulated.
X X X X
2. .........................
Surface Operations (Pre-Take-Off)
2.a. ...............
Engine Start
2.a.1. .....
Normal start .........................................................................................................................
X X X X
2.a.2. .....
Alternate start procedures ...................................................................................................
X X X X
2.a.3. .....
Abnormal starts and shutdowns (e.g., hot/hung start, tail pipe fire) ...................................
X
X
X
X
2.b. ...............
Pushback/Powerback ..........................................................................................................
X X X
2.c. ...............
Taxi
2.c.1. .....
Thrust response ..................................................................................................................
X X X X
2.c.2. .....
Power lever friction ..............................................................................................................
X X X X
2.c.3. .....
Ground handling ..................................................................................................................
X X X X
2.c.4. .....
Nosewheel scuffing .............................................................................................................
X X
2.c.5. .....
Brake operation (normal and alternate/emergency) ...........................................................
X
X
X
X
2.c.6. .....
Brake fade (if applicable) ....................................................................................................
X X X X
3. .........................
Take-off.
3.a. ...............
Normal.
3.a.1. .....
Airplane/engine parameter relationships .............................................................................
X X X X
3.a.2. .....
Acceleration characteristics (motion) ..................................................................................
X X X X
3.a.3. .....
Nosewheel and rudder steering ..........................................................................................
X X X X
3.a.4. .....
Crosswind (maximum demonstrated) .................................................................................
X
X X X
3.a.5. .....
Special performance (e.g., reduced V
1
, max de-rate, short field operations) ....................
X
X
X
X
3.a.6. .....
Low visibility take-off ...........................................................................................................
X X X X
3.a.7. .....
Landing gear, wing flap leading edge device operation .....................................................
X
X
X
X
