14 CFR Ch. I (1–1–14 Edition)
Pt. 60, App. B
T
ABLE
B1A—M
INIMUM
FTD R
EQUIREMENTS
—Continued
QPS Requirements
Information
Entry No.
General FTD requirements
FTD level
Notes
4 5 6
3.a. .............
All relevant instrument indications involved in
the simulation of the airplane must automati-
cally respond to control movement or external
disturbances to the simulated airplane; e.g.,
turbulence or winds.
X X
3.b. .............
Navigation equipment must be installed and op-
erate within the tolerances applicable for the
airplane.
X X
Level 6 must also include communication equip-
ment (inter-phone and air/ground) like that in
the airplane and, if appropriate to the oper-
ation being conducted, an oxygen mask
microphone system.
Level 5 need have only that navigation equip-
ment necessary to fly an instrument approach.
3.c. .............
Installed systems must simulate the applicable
airplane system operation, both on the ground
and in flight. Installed systems must be opera-
tive to the extent that applicable normal, ab-
normal, and emergency operating procedures
included in the sponsor’s training programs
can be accomplished.
X X X
Level 6 must simulate all applicable airplane
flight, navigation, and systems operation.
Level 5 must have at least functional flight and
navigational controls, displays, and instrumen-
tation.
Level 4 must have at least one airplane system
installed and functional.
3.d. .............
The lighting environment for panels and instru-
ments must be sufficient for the operation
being conducted.
X
X
X Back-lighted panels and instruments may be in-
stalled but are not required.
3.e. .............
The FTD must provide control forces and con-
trol travel that correspond to the airplane
being simulated. Control forces must react in
the same manner as in the airplane under the
same flight conditions.
X
3.f. .............
The FTD must provide control forces and con-
trol travel of sufficient precision to manually
fly an instrument approach.
X
4. Instructor or Evaluator Facilities
4.a. .............
In addition to the flight crewmember stations,
suitable seating arrangements for an instruc-
tor/check airman and FAA Inspector must be
available. These seats must provide adequate
view of crewmember’s panel(s).
X
X
X
These seats need not be a replica of an aircraft
seat and may be as simple as an office chair
placed in an appropriate position.
4.b. .............
The FTD must have instructor controls that per-
mit activation of normal, abnormal, and emer-
gency conditions as appropriate. Once acti-
vated, proper system operation must result
from system management by the crew and
not require input from the instructor controls.
X X X
5. Motion System (not required)
