Federal Aviation Administration, DOT

Pt. 60, App. B

T

ABLE

B1A—M

INIMUM

FTD R

EQUIREMENTS

—Continued

QPS Requirements

Information

Entry No.

General FTD requirements

FTD level

Notes

4 5 6

5.a. .............

The FTD may have a motion system, if desired,

although it is not required. If a motion system
is installed and additional training, testing, or
checking credits are being sought on the
basis of having a motion system, the motion
system operation may not be distracting and
must be coupled closely to provide integrated
sensory cues. The motion system must also
respond to abrupt input at the pilot’s position
within the allotted time, but not before the
time when the airplane responds under the
same conditions.

X

X

The motion system standards set out in part 60,

Appendix A for at least Level A simulators is
acceptable.

5.b. .............

If a motion system is installed, it must be meas-

ured by latency tests or transport delay tests
and may not exceed 300 milliseconds. Instru-
ment response may not occur prior to motion
onset.

X

The motion system standards set out in part 60,

Appendix A for at least Level A simulators is
acceptable.

6. Visual System

6.a. .............

The FTD may have a visual system, if desired,

although it is not required. If a visual system
is installed, it must meet the following criteria:

X X X

6.a.1. ..........

The visual system must respond to abrupt input

at the pilot’s position.

An SOC is required.

X X

6.a.2. ..........

The visual system must be at least a single

channel, non-collimated display.

An SOC is required.

X X X

6.a.3. ..........

The visual system must provide at least a field-

of-view of 18

°

vertical / 24

°

horizontal for the

pilot flying.

An SOC is required.

X X X

6.a.4. ..........

The visual system must provide for a maximum

parallax of 10

°

per pilot.

An SOC is required.

X X X

6.a.5. ..........

The visual scene content may not be distracting
An SOC is required.

X X X

6.a.6. ..........

The minimum distance from the pilot’s eye posi-

tion to the surface of a direct view display
may not be less than the distance to any front
panel instrument.

An SOC is required.

X X X

6.a.7. ..........

The visual system must provide for a minimum

resolution of 5 arc-minutes for both computed
and displayed pixel size.

An SOC is required.

X X X
