14 CFR Ch. I (1–1–14 Edition)
Pt. 60, App. B
T
ABLE
B2A—F
LIGHT
T
RAINING
D
EVICE
(FTD) O
BJECTIVE
T
ESTS
—Continued
QPS requirements
Test
Tolerances
Flight conditions
Test details
FTD
level
Information
Entry No.
Title
5 6
Notes
1.f.1.
.........
Acceleration
........................
Level 6:
±
10% T
t
, or
±
0.25
sec.
Level 5:
±
1 sec
...................
Approach
or
Landing
..........
Record engine power (N
1
, N
2
, EPR,
Torque, Manifold Pressure) from idle to
maximum takeoff power for a rapid
(slam) throttle movement.
X
X
See Appendix F of this part
for definitions of T
i
and
T
t
.
1.f.2.
.........
Deceleration
........................
Level 6:
±
10% T
t
, or
±
0.25
sec.
Level 5:
±
1 sec
...................
Ground
................................
Record engine power (N
1
, N
2
, EPR,
Torque, Manifold Pressure) from max-
imum takeoff power to idle for a rapid
(slam) throttle movement.
X
X
See Appendix F of this part
for definitions of T
i
and
T
t
.
2. Handling Qualities
For FTDs requiring Static tests at the controls (i.e., column, wheel, rudder pedal), special test fixtures will not be required
during initial
or upgrade evaluations if the sponsor’s QTG/MQTG shows both test fixture results and the results of an alternative approach, su
ch as
computer plots produced concurrently, that show satisfactory agreement. Repeat of the alternative method during the initial or
upgrade
evaluation would then satisfy this test requirement.
Testing of position versus
force is not applicable if
forces are generated
solely by use of airplane
hardware in the FTD.
2.a.
...........
Static Control Tests
2.a.1.a.
.....
Pitch Controller Position vs.
Force and Surface Posi-
tion Calibration.
±
2 lb (0.9 daN) breakout,
±
10% or
±
5 lb (2.2 daN)
force,
±
2
°
elevator.
Ground
................................
Record results for an uninterrupted control
sweep to the stops.
X
2.a.1.b.
.....
Pitch Controller Position vs.
Force.
±
2 lb (0.9 daN) breakout,
±
10% or
±
5 lb (2.2 daN)
force.
As
determined
by
sponsor
..
Record results during initial qualification
evaluation for an uninterrupted control
sweep to the stops. The recorded toler-
ances apply to subsequent comparisons
on continuing qualification evaluations.
X
Applicable only on con-
tinuing qualification eval-
uations. The intent is to
design the control feel for
Level 5 to be able to
manually fly an instru-
ment approach; and not
to compare results to
flight test or other such
data.
2.a.2.a.
.....
Roll Controller Position vs.
Force and Surface Posi-
tion Calibration.
±
2 lb (0.9 daN) breakout,
±
10% or
±
3 lb (1.3 daN)
force,
±
2
°
aileron,
±
3
°
spoiler angle.
Ground
................................
Record results for an uninterrupted control
sweep to the stops.
X
