62
14 CFR Ch. I (1–1–14 Edition)
Pt. 60, App. A
T
ABLE
A2A—F
ULL
F
LIGHT
S
IMULATOR
(FFS) O
BJECTIVE
T
ESTS
—Continued
QPS Requirements
Information
Test
Tolerance
Flight conditions
Test details
Simulator level
Notes
Entry No.
Title
A B
C
D
..................
The requirements of tests h(1) through (6) of this attachment are applicable to computer controlled aircraft
only. Time history
results are required for simulator response to control inputs during entry into envelope protection limits including both norma
l
and degraded control states if the function is different. Set thrust as required to reach the envelope protection function.
2.h.1.
.............
Overspeed
......................
±
5 kt airspeed
......................
Cruise
..........................
X
X
X
2.h.2.
.............
Minimum Speed
..............
±
3 kt airspeed
......................
Takeoff, Cruise, and
Approach or Landing.
X X X
2.h.3.
.............
Load Factor
.....................
±
0.1 g normal load factor
....
Takeoff, Cruise
............
X
X
X
2.h.4.
.............
Pitch Angle
......................
±
1.5
°
pitch angle
..................
Cruise, Approach
.........
X
X
X
2.h.5.
.............
Bank Angle
.....................
±
2
°
or
±
10% bank angle
......
Approach
.....................
X
X
X
2.h.6.
.............
Angle of Attack
...............
±
1.5
°
angle of attack
...........
Second Segment
Climb, and Approach
or Landing.
X X X
3. Motion System.
3.a.
................
Frequency response.
..................
Based on Simulator Capa-
bility.
N/A
...............................
Required as part of the MQTG. The test
must demonstrate frequency response
of the motion system.
X X X X
3.b.
................
Leg balance.
Based on Simulator Capa-
bility.
N/A
...............................
Required as part of the MQTG. The test
must demonstrate motion system leg
balance as specified by the applicant
for flight simulator qualification.
X X X X
3.c.
................
Turn-around check.
..................
Based on Simulator Capa-
bility.
N/A
...............................
Required as part of the MQTG. The test
must demonstrate a smooth turn-
around (shift to opposite direction of
movement) of the motion system as
specified by the applicant for flight
simulator qualification.
X X X X
