63
Federal Aviation Administration, DOT
Pt. 60, App. A
3.d.
................
Motion system repeatability.
..................
With the same input signal,
the test results must be
repeatable to within
±
0.05
g actual platform linear
acceleration.
Accomplished in both
the ‘‘ground’’ mode
and in the ‘‘flight’’
mode of the motion
system operation.
Required as part of the MQTG. The as-
sessment procedures must be de-
signed to ensure that the motion sys-
tem hardware and software (in normal
flight simulator operating mode) con-
tinue to perform as originally qualified.
X
X
X
X
This test ensures that
motion system hard-
ware and software
(in normal flight sim-
ulator operating
mode) continue to
perform as originally
qualified. Perform-
ance changes from
the original baseline
can be readily identi-
fied with this infor-
mation.
3.e.
................
Motion cueing performance signature. Required as part of MQTG. For the following set of maneuvers record th
e relevant mo-
tion variables.
These tests should be
run with the motion
buffet mode dis-
abled. See para-
graph 6.d., of this at-
tachment, Motion
cueing performance
signature.
3.e.1.
.............
Takeoff rotation (V
R
to
V
2
).
As specified by the sponsor
for flight simulator quali-
fication.
Ground
.........................
Pitch attitude due to initial climb must
dominate over cab tilt due to longitu-
dinal acceleration.
X X X X
Associated
with
test
1.b.4.
3.e.2.
.............
Engine failure between
V
1
and V
R
.
As specified by the sponsor
for flight simulator quali-
fication.
Ground
.........................
X
X
X
X
Associated with test
1.b.5.
3.e.3.
.............
Pitch change during go-
around.
As specified by the sponsor
for flight simulator quali-
fication.
Flight
............................
X
X
X
Associated with test
2.e.6.
3.e.4.
.............
Configuration changes
....
As specified by the sponsor
for flight simulator quali-
fication.
Flight
............................
X
X
X
X
Associated with tests
2.c.2. and 2.c.4.
3.e.5.
.............
Power change dynamics
As specified by the sponsor
for flight simulator quali-
fication.
Flight
............................
X X X X
Associated
with
test
2.c.1.
3.e.6.
.............
Landing flare
...................
As specified by the sponsor
for flight simulator quali-
fication.
Flight
............................
X
X
X
Associated with test
2.e.1.
